ELK-1882T Airborne AESA SATCOM System



3/15/20241 min read

ELK-1882T airborne AESA SATCOM system is a network of SATCOM On-the-Move (SOTM) terminals, based on electronically-steered phased array antenna technology. The system provides Beyond-Line-of-Sight (BLOS) communication
to airborne platforms including fighters and special mission aircraft. The system operates in either Ku or Ka-band frequencies, using geostationary satellites. The network supports hundreds of registered users. The terminal comprises a single LRU which includes
a conformal electronic steering antenna, modem and High-Power Amplifier (HPA). The terminal has a low Radar Cross Section (RCS), and its conformal flat panel antenna creates minimal aerodynamic drag. The terminal is simple to integrate and can be installed on a wide range of aerial platforms.tems

  • Complies with ITU-R 524-9 spectral density regulation for small antenna using Direct Sequence Spread Spectrum technology

  • State of the art Software Defined Radio (SDR) Technology using Adaptive Coding Modulation (ACM) with sophisticated Forward Error Correction (FEC) algorithms

  • Seamless transmission and reception of bi-directional voice and data

  • High spectral efficiency techniques using unique CDMA interference cancelling algorithm

  • High MTBF and graceful degradation due to phased array technology
